A Beginner’s Guide to Adding Hydraulic Fluid to an Excavator

Thursday, March 19, 2026

When we think of excavators, dust and dirt often come to mind, as these machines are frequently used in dusty work environments and handle heavy loads. Regularly refilling the excavator’s hydraulic fluid is essential to keep the hydraulic system functioning properly and ensure the machine operates smoothly.

Refilling an excavator’s hydraulic fluid is an important yet simple task. However, beginners may feel overwhelmed when doing it for the first time. Below, we provide a straightforward guide to help you complete this task with ease.

Table of Contents

≡

I. Common Signs of Hydraulic Fluid Shortage
II. Things You Must Do Before Adding Excavator Hydraulic Fluid
III. Check Your Current Hydraulic Oil Levels
IV. How to Add Hydraulic Fluid to the Excavator
1. Prepare the correct hydraulic fluid
2. Locate the hydraulic oil tank and fill the port
3. Clean the work area
4. Check the fluid level
5. Add hydraulic fluid
6. Check for leaks
7. Ensure optimal fluid level
8. Replace the cap
9. Start the excavator
V. Safety Precautions When Adding Hydraulic Fluid
VI. Conclusion

I. Common Signs of Hydraulic Fluid Shortage

Promptly recognizing these signs of hydraulic oil shortage can reduce wear and aging of equipment components and enhance operational safety. Here are some common signals to watch out for:

· Abnormal rise in hydraulic system temperature.
· Slower response speed and less agile movements when using an excavator for a project.
· Insufficient power for the excavator to complete normal work tasks.
· Abnormal noise from the hydraulic system during operation, usually cavitation noise caused by the pump running empty.
· Inconsistent hydraulic cylinder movement, such as irregular or intermittent behavior.

If you notice any of these signs, your excavator is low on hydraulic oil and requires immediate checking and refilling. Importantly, be sure to keep the following considerations in mind when adding fluid.

II. Things You Must Do Before Adding Excavator Hydraulic Fluid

Before you begin, ensure the excavator is securely parked on a solid, level surface, and that the hydraulic system has cooled down to a safe operating temperature. Follow the manufacturer’s guidelines to position the boom and bucket in the specified locations, which allows for accurate reading of the hydraulic tank level. Verify that the hydraulic oil level falls between the minimum and maximum marks on the oil sight glass.

III. Check Your Current Hydraulic Oil Levels

Some excavators are equipped with a digital display or indicator light that shows the hydraulic oil level.

Certain models may have a hydraulic oil level indicator inside the cab, displayed on the dashboard or console. Others may require you to open the hydraulic tank cap and check the oil level directly with your eyes.

For the exact hydraulic oil inspection method for your excavator model, refer to the operation manual or contact the manufacturer.

IV. How to Add Hydraulic Fluid to the Excavator

To ensure your excavator operates smoothly in dusty conditions, proper hydraulic fluid refilling is key. Now, let’s go over the correct steps for adding hydraulic fluid:

1. Prepare the correct hydraulic fluid

If you’re unsure about the type of hydraulic fluid to use, consult the excavator’s user manual or manufacturer specifications to ensure you select the correct type and grade. Never mix different types of hydraulic fluids or use fluids designed for other excavator models.

2. Locate the hydraulic oil tank and fill the port

The hydraulic oil tank is usually located at the rear of the excavator, near the hydraulic pump. The fill port is typically on top of the tank, which is a large rectangular container. Remove the fill cap and wipe the port clean with a cloth to prevent dirt or debris from entering.

3. Clean the work area

Before adding hydraulic fluid, clean the area around the work site to avoid impurities or dirt getting into the hydraulic system.

4. Check the fluid level

Maintaining the correct hydraulic fluid level is vital for the smooth and efficient operation of heavy machinery. Locate the hydraulic oil tank and use the dipstick or sight gauge on the tank’s side to check the level. If it’s low, move on to the next step; if it’s already full, do not add more fluid.

5. Add hydraulic fluid

Open the hydraulic oil tank’s top cap and slowly pour in the hydraulic fluid, taking care not to overfill. Use a funnel if needed to avoid spills.

6. Check for leaks

After adding the fluid, inspect the excavator for any signs of leaks, such as hydraulic fluid stains near the machine. This step is critical—if leaks are found, address them immediately to prevent further damage. Also, pay attention to any unusual sounds or movements while filling the fluid.

7. Ensure optimal fluid level

Double-check the fluid level to ensure it’s at the proper level. This is a crucial step—don’t skip it!

8. Replace the cap

Once you’ve added the hydraulic fluid and completed all necessary checks, securely fasten the cap on the hydraulic oil reservoir.

9. Start the excavator

Start the excavator and let the hydraulic system run for a few minutes to circulate the new fluid. Then, check the fluid level again—your excavator will thank you!

By following these steps, you can effectively and safely maintain your excavator.

V. Safety Precautions When Adding Hydraulic Fluid

If a leak is suspected, do not use your hands to search for it along hydraulic hoses or components. Instead, use tools like mirrors to locate potential leaks and avoid the risk of fluid injection injuries.
When adding hydraulic fluid, wear appropriate personal protective equipment, such as goggles and gloves. This will protect you from hydraulic oil contamination and other potential hazards.
Adding hydraulic fluid involves manual tasks, such as lifting and carrying fluid containers. Exercise extra care during these operations to prevent accidents.
Maintain clear communication with those around you while adding fluid. This ensures everyone is aware of the current work status and safety measures.
When checking hydraulic fluid, ensure the machine is turned off. Injuries caused by operating machinery can be unpredictable.
Take proper steps to confirm the fluid level. Do not rely on visual estimates or poor lighting to judge the hydraulic oil level—for example, remove the tank cap to check directly. Ensuring the correct fluid level is a key part of routine maintenance.
These safety precautions also apply to inspecting and replacing hydraulic fluid.

VI. Conclusion

Refilling an excavator’s hydraulic fluid is an important task, and beginners may naturally be cautious. Knowing when to add more fluid is key to keeping your equipment running efficiently. Additionally, you may want to prepare spare excavator parts related to the hydraulic system for timely replacement. Always prioritize safety—with the right precautions, you can use the guidelines above and the user manual to add hydraulic fluid correctly, which will greatly benefit your equipment. If you’re an experienced operator, make hydraulic fluid refilling a regular task to prevent unexpected breakdowns. Get started, and good luck with your work!
