The "Joint Hub" of Excavators! A Complete Guide to Pins & Bushings

2. Importance: Without Pins & Bushings, the Excavator Is a "Stiff Iron Block"

• Foundation for Movement: All components that need to rotate rely on pins & bushings to move — without boom pins, the boom cannot lift; without bucket bushings, the bucket cannot close, and the machine becomes completely "immobile";

• Protection for Major Components: The buffering effect of bushings can reduce impact damage to hydraulic cylinders, booms, and arms — for example, when the bucket hits hard soil, the bushings can absorb 30% of the impact force, preventing cracks in the arm articulation holes (repairing an arm costs USD 1,375 - USD 4,125, while replacing a bushing only costs USD 27.5 - USD 68.75);

• Impact on Operating Efficiency: After pins & bushings are worn, gaps will appear at the articulation points, leading to jerky movements and abnormal noises — for example, worn arm pins cause the bucket to "wobble" when closing, taking an extra 10 seconds to fill a bucket of soil, resulting in 20 - 30 fewer buckets dug per day;

• "Small Parts, Big Costs" in Maintenance: A single set of pins & bushings is not expensive (domestic ones cost USD 27.5 - USD 137.5, imported ones cost USD 68.75 - USD 275), but replacing them requires disassembling the boom and hoisting the bucket, with labor costs ranging from USD 275 - USD 687.5. If severe wear causes deformation of the articulation holes, boring repairs are needed, increasing the cost by USD 1,375 - USD 2,750.

II. 5 Things Pins & Bushings Fear the Most!

1. Insufficient Lubrication: Dry Friction Causes Rapid Wear

• Risk Manifestation: Forgetting to add grease to the articulation points or adding too little grease results in no oil film between the pins and bushings, leading to "dry friction" — for example, if the boom pins are not lubricated for 3 months, the chrome - plated surface will be worn off, and the exposed steel body will rust within a week; dry friction of the bucket bushings will produce a "squeaking sound", and the wear will exceed 0.5mm within a month, causing looseness at the articulation points;

• Maintenance Cost: Replacing a set of worn pins & bushings costs USD 68.75 - USD 275. If the articulation holes are damaged, boring repairs cost USD 1,375 - USD 2,750.

2. Impurities Entering Articulation Points: Like "Sand in Joints", Accelerating Wear

• Risk Manifestation: Gravel, soil, and dust on the construction site can enter the gaps between the pins and bushings. These impurities act like "sandpaper", wearing the inner walls of the bushings and the surfaces of the pins — for example, when working in a gravel yard, gravel entering the articulation point between the arm and the bucket will wear out the bushings within a week, causing the bucket to wobble;

• Common Scenario: Adding grease without cleaning the impurities around the articulation points will "press" the impurities into the gaps, which instead intensifies wear.

3. Long - Term Exposure to Impact Loads: Bushing Cracking and Pin Bending

• Risk Manifestation: Not avoiding hard rocks when digging with the bucket or forcibly hitting obstacles with the boom causes the articulation points to bear excessive impact loads — for example, when a 20 - ton excavator hits a concrete pile with the bucket, the bucket pin will bend due to an instantaneous force exceeding 20 tons, and the bushing will also be crushed;

• Maintenance Cost: Replacing a bent pin costs USD 110 - USD 206.25, correcting the deformed articulation holes costs over USD 1,375, and the downtime is at least 2 days.

4. No Maintenance in Water - Wading or Humid Environments: Pin Rusting and Bushing Corrosion

• Risk Manifestation: After working on rainy days or wading in muddy areas, water can enter the articulation points, causing the pins to rust and the bushings (especially steel bushings) to corrode — rusted pins will scratch the inner walls of the bushings, and corroded bushings will lose their wear resistance, resulting in gaps within 3 - 5 days;

• Incorrect Practice: Not cleaning the articulation points after wading and directly parking the machine will cause water to remain in the gaps for a long time, accelerating rusting.

5. Improper Installation: Excessive or Insufficient Gaps

• Risk Manifestation: Using pins & bushings of incorrect specifications (e.g., installing a thin pin in a large hole) during replacement or forcibly knocking them in (causing bushing deformation) will result in "excessive gaps" (wobbly movements) or "insufficient gaps" (jerky rotation) — for example, an overly tight arm bushing installation will cause the arm to "jam" when extending and retracting, and also wear out the pin;

• Maintenance Cost: Re - replacing with suitable pins & bushings costs USD 68.75 - USD 137.5. If bushing deformation causes wear to the articulation holes, the hole diameter needs to be expanded to install a larger bushing, increasing the cost by USD 275 - USD 412.5.

III. Cost - Effectiveness Comparison of Pins & Bushings from Domestic and Foreign Excavator Brands: Choose the Right One to Reduce Repairs and Costs!
