Hitachi EX60 Excavator: Parts Lookup & Complete Specifications
EX60 Hitachi Excavator Specifications Lookup
Boom/Stick Excavator Option
| Item | Specification |
|---|---|
| Max Cutting Height | 23.5 ft (7 m)/ 24.8 ft (7 m) |
| Max Digging Depth | 13.7 ft (4 m)/ 15.3 ft (5 m) |
| Max Loading Height | 16.7 ft (5 m)/18 ft (5 m) |
| Max Reach Along Ground | 20.3 ft (6 m)/ 21.9 ft (6 m) |
| Max Vertical Wall Digging Depth | 11.6 ft (3 m)/ 13.4 ft (4 m) |
| Shipping Height of Unit | 8.5 ft (2 m)/ 9.5 ft (3 m) |
| Shipping Length of Unit | 20 ft (6 m)/ 20.1 ft (6 m) |
Bucket
| Item | Specification |
|---|---|
| Maximum Bucket Capacity | 0.5 cu yds (0 m³) |
| Minimum Bucket Capacity | 0.2 cu yds (0 m³) |
| Reference Bucket Capacity | 0.4 cu yds (0 m³) |
Dimensions
| Item | Specification |
|---|---|
| Ground Clearance | 1.2 ft (0 m) |
| Height – Top of Cab | 8.5 ft (2 m) |
| Removal Counterweight Clearance | 2.5 ft (1 m) |
| Tail Swing Radius | 5.8 ft (2 m) |
| Width to Outside of Tracks | 7.3 ft (2 m) |
Engine
| Item | Specification |
|---|---|
| Aspiration | Natural |
| Displacement | 180.3 cu in (0 m³) |
| Engine Make | 2311 |
| Engine Model | A-BD30 |
| Max Torque | 133.5 lbs/ft |
| Net Power | 54 hp (40 kw) |
| Power Measured @ | 2200 rpm |
| Torque Measured @ | 1500 rpm |
Operating Specifications
| Item | Specification |
|---|---|
| Alternator Supplied Amperage | 25 A |
| Cooling System Fluid Capacity | 2.7 gal (8 l) |
| Engine Oil Capacity | 3.4 gal (11 l) |
| Fuel Capacity | 9.5 gal (34 l) |
| Hydraulic Pump Flow Capacity | 41.9 gal/min (155 l/min) |
| Hydraulic System Fluid Capacity | 23.8 gal (87 l) |
| Hydraulic System Relief Valve Pressure | 4550 psi |
| Operating Voltage | 12 V |
| Operating Weight | 13889.2 lbs (6,300 kg) |
| Swing Drive Fluid Capacity | 0.5 gal (0 l) |
Swing Mechanism
| Item | Specification |
|---|---|
| Swing Speed | 14.5 rpm |
Undercarriage
| Item | Specification |
|---|---|
| Ground Pressure | 4.3 psi |
| Max Travel Speed | 3 mph (5 kph) |
| Number of Carrier Rollers per Side | 1 |
| Number of Shoes per Side | 37 |
| Number of Track Rollers per Side | 5 |
| Shoe Size | 17.8 in (43 cm) |
